Full load current calculator
Calculate the full load current of motors or electrical equipment from power, voltage, and power factor. Works for single-phase and three-phase systems.
full load current calculator
Full load current is the current taken up when electrical equipment is at full load capacity. To determine amps use the right equation either of a single phase or three phase.
Formula & Table Summary:
HP to kW: \( P_{\text{kW}} = \text{HP} \times 0.746 \)
Single-phase: \( I = \frac{P_{\text{kW}} \times 1000}{V \times \text{PF}} \)
Three-phase: \( I = \frac{P_{\text{kW}} \times 1000}{\sqrt{3} \times V \times \text{PF}} \)
load current calculation
The Full Load Current Calculator determines the amps of motors or equipment given single-phase, three-phase, rated power, and power factor. This parameter is important to size protective devices, cables and electrical panels. The power factor and the rated efficiency of motors is generally available and it must be employed in calculations to make them more precise. This tool can take kW and HP values as input and one may find an easy way to convert horsepower to KW and obtain the full load current. Electricians, engineers, and technicians find it useful to make sure that the electrical systems are properly designed, that they are not overloaded, and that high safety levels are retained in the industrial and residential sections.
3 phase full load current
| Motor Power | Voltage (V) | Phase | PF | kW | Full Load Current (A) |
|---|---|---|---|---|---|
| 1 HP | 230 | Single | 0.85 | 0.746 | 3.83 |
| 5 HP | 230 | Single | 0.85 | 3.73 | 19.15 |
| 5 HP | 400 | Three | 0.85 | 3.73 | 6.33 |
| 10 HP | 400 | Three | 0.85 | 7.46 | 12.66 |
| 20 HP | 400 | Three | 0.85 | 14.92 | 25.33 |
Frequently Asked Questions - Full load current calculator:
What is full load current?
It is the current drawn when a motor or equipment operates at its rated load.
How do I calculate full load current for a single-phase motor?
I = (P*1000)/(V*PF).
How do I calculate full load current for a three-phase motor?
I = (P*1000)/(√3*V*PF).
Does power factor affect full load current?
Yes, lower PF increases current draw.
Can I use HP instead of kW?
Yes, convert HP to kW by multiplying by 0.746.
Why is my motor drawing more current than calculated?
Possible causes include overload, low voltage, or mechanical issues.
Can I use this for generators?
Yes, if you know rated power, voltage, and power factor.
What is the importance of FLC?
It ensures correct breaker, fuse, and wire sizing.
Does efficiency affect FLC?
Yes, lower efficiency increases input power and current.
Is FLC same as starting current?
No, starting current is much higher than FLC.
